Comprehensive and Detailed Step-by-Step Explanation:

To determine the correct device, we need to understand how a DOCSIS (Data Over Cable Service Interface Specification) network functions in a Small Office/Home Office (SOHO) environment:

C. Cable Modem:

A cable modem is required to convert the signal provided by the ISP (Internet Service Provider) over a DOCSIS network into a format that is usable by the local area network (LAN).

DOCSIS is a standard for high-speed internet over cable television infrastructure, and the cable modem acts as the gateway between the ISP ' s coaxial network and the LAN.

Without the cable modem, devices in the LAN would not be able to access the internet.

A firewall monitors and filters incoming and outgoing network traffic based on security rules, protecting the network from unauthorized access and threats.

Why Not A (Switch): A switch connects devices within a network but does not monitor or filter traffic.

Why Not B (Access point): An access point provides Wi-Fi connectivity but does not filter traffic.

Why Not D (Hub): A hub simply broadcasts data to all connected devices without filtering traffic.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 2.2, network security concepts​.

Physical damage from dropping a tablet may often affect ports or connectors. Before taking deeper diagnostic or replacement steps, it ' s important to visually inspect the USB-C charging port for damage or debris. If the port is damaged, charging issues can occur regardless of battery health.

When a device shows asnot connectedeven though it previously paired, the most effective action is tore-pair the devices. This resets the Bluetooth connection, clears any corruption in pairing profiles, and re-establishes communication.

Option A:Entering a PIN is only relevant during initial pairing and may not be prompted again.

Option B:Turning off Wi-Fi doesn’t typically affect Bluetooth; they operate on similar frequencies but don’t conflict this way in normal use.

Option D:If Bluetooth were disabled, the device wouldn’t appear at all, not just show as “not connected.”

CompTIA A+ Core 1 Exam Objective Reference:

Objective 1.5: Given a scenario, connect and configure accessories and ports of mobile devices.

The most likely failed component in this scenario is the touch screen. According to CompTIA Core 1 (220-1201) mobile device hardware and troubleshooting objectives, smartphones rely on the digitizer (touch screen layer) to detect user input such as taps, swipes, and on-screen keyboard presses. If the device powers on and displays the lock screen but does not register code input, this strongly indicates a failure in the touch input functionality.

A failed charging port would prevent the device from charging but would not affect the ability to enter a passcode if the device is powered on. An OLED failure would result in display issues such as a blank screen, flickering, discoloration, or no image at all—none of which are described in this scenario. A biometric scanner (fingerprint or facial recognition) failure would only impact biometric authentication methods; users would still be able to unlock the phone using a PIN or passcode.

CompTIA emphasizes distinguishing between display output issues and input issues when troubleshooting mobile devices. Since the problem specifically involves unsuccessful code entry despite the phone being operational, the root cause is the touch screen.

Degraded performance that occurs only during business hours strongly suggests network congestion caused by simultaneous data and voice traffic. According to CompTIA Core 1 (220-1201) networking objectives, combining voice (VoIP) and data traffic on the same network without proper segmentation can lead to latency, jitter, and packet loss, especially during peak usage periods.

Implementing VLANs (Virtual Local Area Networks) allows administrators to logically separate voice and data traffic, enabling better traffic management and prioritization. VLANs also support Quality of Service (QoS) policies that ensure time-sensitive voice traffic is prioritized over standard data traffic, improving call quality and overall performance.

Replacing switches with higher-capacity models is costly and unnecessary if proper traffic segmentation has not yet been implemented. Adding RAM to PCs or VoIP lines does not address network-level congestion. Firmware updates may improve stability but will not resolve sustained performance degradation caused by traffic contention.

CompTIA highlights VLAN implementation as a best practice for environments that use IP phones, especially when performance issues occur during high utilization periods.

The correct answer is B. Change the resolution.

According to the CompTIA A+ Core 1 220-1201 objectives, troubleshooting display issues involves checking the display settings, including resolution, scaling, and orientation. When a projector is only showing part of a laptop screen:

The most common cause is that the laptop’s output resolution does not match the projector ' s native resolution. If the laptop is set to a resolution larger than what the projector supports, only a portion of the screen is visible.

The technician should first adjust the laptop ' s resolution to match the projector’s native resolution before attempting other options like extending or mirroring the desktop.

Why the other options are incorrect:

A. Extend the desktop: This is only used if the user wants to have two separate screens (dual monitors), not to fix partial display issues.

C. Mirror the desktop: Mirroring duplicates the laptop display but does not solve issues caused by resolution mismatch.

D. Switch the input source: Necessary only if the projector is on the wrong input, but the problem here is a partial display, not no display.

DHCP Dynamic Host Configuration Protocol is the service that automatically assigns IP addresses and other essential network settings to devices when they join a network. Instead of manually configuring each device with an IP address, subnet mask, default gateway, and DNS servers, a DHCP server provides these settings dynamically from a defined address pool. This reduces configuration errors, prevents IP conflicts, and makes network administration easier—especially in environments with many devices or frequent changes. In the DHCP process, a client broadcasts a request, the DHCP server offers an address, the client requests that offered address, and the server acknowledges it, granting the device a lease for a specific period. The lease can be renewed, and administrators can also configure reservations to always give the same IP to a particular device based on its MAC address.

DNS is used for resolving hostnames to IP addresses, not assigning them. SMTP is for sending email between mail servers and clients. SNMP is used for monitoring and managing network devices. Therefore, DHCP is the correct service for automatically assigning IP addresses.
