A Layer 3 switch is the optimal solution when multiple VLANs must intercommunicate while maintaining high performance and minimal hardware complexity. CompTIA A+ explains that Layer 3 switches combine the capabilities of switching (Layer 2) and routing (Layer 3), allowing VLAN traffic to be routed internally at wire speed, without the latency typically associated with traditional routers.

Layer 3 switches use hardware-based routing, meaning they forward inter-VLAN traffic using ASICs (Application-Specific Integrated Circuits). This allows them to achieve extremely fast throughput, ideal for environments like computer training institutes where multiple VLANs may be used for student labs, instructor networks, and administrative traffic.

A router (D) can route between VLANs but introduces more latency due to software-based routing and typically requires additional equipment. A Web application firewall (A) and DDoS appliance (B) are security devices unrelated to internal VLAN communication.

Because the institute requires minimal hardware and high-speed inter-VLAN communication, the Layer 3 switch is the only CompTIA-supported device that meets both requirements simultaneously.

If a laptop shuts down when undocked and remains powered off even with a new charging cable, the internal battery is likely faulty and cannot hold a charge. Replacing the battery is the next troubleshooting step.

From the CompTIA A+ 220-1101 Official Study Guide, Objective 4.1 – Troubleshoot common hardware problems:

"If a laptop only works when docked or connected to AC power, and a replacement cable does not resolve the issue, the internal battery may need to be replaced."

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 4: Troubleshooting Mobile Devices

CompTIA Exam Objectives 220-1101, Domain 4.1

============

Ultra HD (UHD), also referred to as4K UHD, has a resolution of3840x2160. It's four times the resolution of standard 1080p (Full HD), offering more screen real estate and sharper images.

Option A (1920x1080):Full HD (FHD), not UHD.

Option B (2048x1080):DCI 2K used in cinema, not common for Ultra HD.

Option D (7680x4320):Known as 8K UHD, not standard Ultra HD.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 1.7: Compare and contrast display technologies and their features.

===========

Comprehensive and Detailed Explanation From Exact Extract:

A firewall allows for detailed traffic control, including blocking outbound connections while allowing inbound ones. This is contrary to typical security setups, but it can be configured via advanced firewall rules.

Single-mode fiber (as well as multi-mode fiber) transmits data using beams of light, allowing for high-speed data transfer over flexible fiber-optic cables.

From CompTIA A+ 220-1101 Official Study Guide, Objective 2.1 – Networking media:

“Fiber optic cables transmit data using light. Single-mode fiber is used for long-distance, high-speed communication.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Networking Media

CompTIA Exam Objectives 220-1101, Domain 2.1

============

Cloud storage platforms—such as OneDrive, Google Drive, and Dropbox—use synchronization to ensure that files updated on one device automatically update on all connected devices. CompTIA A+ defines synchronization as a key cloud characteristic that keeps local folders and cloud-stored versions consistent, enabling seamless multi-device collaboration.

Synchronization allows users to:

Modify files offline and have them sync once online

Access identical data on laptops, desktops, and mobile devices

Ensure real-time updates across multiple users or clients

Maintain version consistency and conflict resolution

A network share (A) is local to an organization and does not automatically sync across devices. Availability (C) relates to uptime and reliability, not file updates. Metered utilization (D) refers to cloud billing models where usage is tracked, not data syncing.

Thus, synchronization is the capability that ensures local folders update dynamically whenever changes occur.

The baseline documentation says the valid network range ends at 192.168.232.255, but the user’s gateway is 192.168.233.1, which is outside the permitted network range. CompTIA A+ emphasizes that devices must have a gateway inside their own subnet.

Given a mask of 255.255.255.0, the user’s subnet is 192.168.223.x, so the gateway must be in 192.168.223.x, not 192.168.233.x.

DNS settings are public and acceptable. The IP address and subnet mask are valid within the documented address space.

Therefore, the incorrect setting is the gateway, which prevents external routing. Correcting it resolves the connection issue, matching CompTIA’s routing and TCP/IP troubleshooting procedures.
