When the keyboard backlight turns on, the laptop is receiving power and at least partially completing its startup hardware initialization. A black internal display can be caused by multiple issues, including a failed LCD/backlight, a loose or damaged display cable, an incorrect display output selection, or a graphics subsystem problem. The best next troubleshooting step is to connect the laptop to an external monitor because it quickly isolates whether the problem is with the internal display assembly or with the system’s ability to generate video at all.

If the external monitor displays video normally, the GPU and motherboard are likely functioning, and the technician should focus on the laptop’s internal screen components such as the LCD panel, backlight, display cable, or connector seating—often accessed by removing the bezel only after confirming this. If the external monitor also shows no video, the issue is more likely related to graphics output, memory, motherboard, or firmware/POST problems, and further internal diagnostics are required. Plugging in a charger is reasonable if the device seems underpowered, but it does not directly test the video path. Replacing the laptop is not an appropriate “next step” in troubleshooting.

If a user can send email but cannot receive email, the most likely issue is with the incoming mail configuration rather than the outgoing mail configuration. SMTP is primarily used for sending mail from a client to a mail server (and between mail servers), so working outbound email strongly suggests SMTP settings are correct. To receive email, the client must connect to an incoming mail service such as IMAP (or POP3). Therefore, the first setting to verify on the laptop is the IMAP configuration, including the incoming server address, port number, encryption method (SSL/TLS), and authentication credentials. If any of these are wrong, the client may fail to synchronize the mailbox, making it appear that mail is not arriving even though messages exist on the server.

DNS can affect both sending and receiving because clients must resolve mail server hostnames, but when the symptom is specifically “send works, receive fails,” checking the dedicated incoming protocol settings is the most direct and likely fix. DMARC is an email authentication policy used at the domain level and is not a laptop-side setting the technician would check first for a single user’s inbound mail problem.

ECC (Error-Correcting Code) RAM is commonly used in servers to provide error detection and correction, improving reliability in critical systems. It is designed to detect and correct single-bit errors, ensuring data integrity in environments where stability is paramount.

Option A (SODIMM): Incorrect. SODIMM is typically used in laptops, not servers.

Option B (Rambus): Incorrect. Rambus is an outdated RAM type and not commonly used today.

Option C (DDR3): Incorrect. While DDR3 is a type of RAM, it is not specific to servers and does not provide error correction.

A CNAME (Canonical Name) record is used in DNS to create an alias that maps one domain name to another canonical domain name. According to CompTIA Core 1 (220-1201) DNS objectives, CNAME records allow multiple hostnames to reference the same IP address indirectly by pointing to a single authoritative domain name.

For example, www.example.com can be configured as a CNAME that points to example.com. When DNS queries are made, the resolver follows the alias until it reaches an A or AAAA record that contains the actual IP address.

An A record maps a hostname directly to an IPv4 address, while an AAAA record maps a hostname to an IPv6 address. A TXT record is used to store arbitrary text data, commonly for verification, email security (SPF, DKIM), or policy information, not for aliasing.

CompTIA stresses that CNAME records are specifically intended for aliasing and name redirection within DNS, making them the correct answer.

When a workstation automatically assigns itself an IP address that is not part of the DHCP lease pool, the system has most likely configured an APIPA (Automatic Private IP Addressing) address. According to CompTIA Core 1 (220-1201) networking fundamentals, APIPA addresses fall within the range 169.254.0.0/16 and are assigned when a device cannot communicate with a DHCP server.

APIPA allows limited local network communication but does not provide access to the internet or network resources such as internal file shares that require routing or proper IP configuration. This explains why the workstation experiences connectivity issues.

A static IP address is manually configured and would not be automatically assigned. A DHCP address would come from the defined lease pool, which the technician has confirmed is not the case. A public IP address is assigned by an ISP and is not used directly on internal workstations.

CompTIA highlights APIPA as a key troubleshooting indicator of DHCP failure or network connectivity issues, making it the correct answer.

The 12VHPWR connector can supply up to 600 watts of power, designed for high-end graphics cards.

Why Not A (400W): This is less than the connector’s maximum capability.

Why Not B (MOW): This is an invalid option.

Why Not D (700W): The maximum supported power is 600W.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 3.4, power supply and connectors​.
