300-410 Exam Dumps - Implementing Cisco Enterprise Advanced Routing and Services (300-410 ENARSI)

A route received from one iBGP peer will NOT be advertised to another iBGP peer. Therefore R4 could not receive advertisement for network 192.168.100.0/24. We can overcome this BGP limitation by configuring R1 as a route reflector server and R4 as a route reflector client so that R1 sends advertisements for R4.

Diagram Description automatically generated

The MPLS LDP Inbound Label Binding Filtering feature can be used to control the amount of

memory used to store Label Distribution Protocol (LDP) label bindings advertised by other

devices. For example, in a simple Multiprotocol Label Switching (MPLS) Virtual Private Network

(VPN) environment, the VPN provider edge (PE) devices might require label switched paths

(LSPs) only to their peer PE devices (that is, they do not need LSPs to core devices). Inbound

label binding filtering enables a PE device to accept labels only from other PE devices.

To turn off terminal monitor, use “terminal no monitor” in the enable mode

According to this question, uRPF is running in strict mode because packets are dropped even

when that route exists in the routing table. Maybe packets are dropped because the receiving

interface is different from the interface the local router uses to send packets to that destination.

The ip verify unicast source reachable-via rx command enables Unicast RPF in strict mode.

To enable loose mode, administrators can use the any option (ip verify unicast source

reachable-via any). In loose mode, it doesn’t matter if we use this interface to reach the source

or not.

The allow-default option allows the use of the default

route in the source verification process.

--------------------------R1---------------------------------------------

interface Ethernet0/0

ip address 209.165.201.1 255.255.255.0

ip access-group EGRESS2 out

ipv6 address 2001:DB8::1/64

end

----------------------R2--------------------------------------------------

interface Ethernet0/0

ip address 209.165.201.25 255.255.255.0

ipv6 address 2001:DB8::2/64

ipv6 address autoconfig

ipv6 nd autoconfig default-route

ipv6 nd cache expire 60

ipv6 nd ra suppress

ipv6 traffic-filter INGRESS in

end

IOU_Router2#telnet 2001:DB8::1

Trying 2001:DB8::1 ... Open

IOU_Router1>

------------------------------------------------------------------------------

VPNv4 address consists of 64-bit Route Distinguisher (RD) prepended to IPv4 prefix. This is to

make routes unique that are in different VRFs.

A Multiprotocol Label Switching(MPLS) Layer 3 Virtual Private Network (VPN) consists of a set

of sites that are interconnected by means of an MPLS provider core network. At each customer

site, one or more customer edge (CE) routers attach to one or more provider edge (PE) routers.
