 The configuration snippet in the image is a part of IKEv2 configuration where the name mangler is associated with the organizational unit (OU) “MANGLER”. In Cisco’s IKEv2 implementation, this specific configuration means that only an IKEv2 peer whose certificate has an OU attribute set to “MANGLER” can establish an IKEv2 Security Association successfully. This is a method of ensuring that only peers with certificates issued to a specific organizational unit can connect, enhancing security by limiting unauthorized access. The name mangler is a feature that allows the administrator to specify a string that must be present in the peer’s certificate for authentication. The name mangler can be applied to any certificate field, such as common name (CN), organization (O), or OU. The name mangler can also be used to modify the peer’s identity based on the certificate field, such as appending or prepending a string to the identity. The name mangler is configured under the IKEv2 profile using the command crypto ikev2 profile profile-name identity name-mangler name-mangler-name dn field-name. In this case, the name mangler is applied to the OU field of the peer’s certificate. The other options are incorrect because they do not describe the effect of the name mangler configuration. Option A is incorrect because the name mangler does not affect the identity matching for the IKEv2 authorization policy. The identity matching is based on the peer’s identity type and value, which can be different from the certificate field. Option C is incorrect because the name mangler does not encrypt the OU field of the peer’s certificate. The OU field is part of the certificate’s subject, which is not encrypted in the IKEv2 messages. Option D is incorrect because the name mangler does not set the OU field of the peer’s certificate. The OU field is determined by the certificate authority (CA) that issues the certificate, and the name mangler only verifies or modifies the peer’s identity based on the OU field. References : Configuring Internet Key Exchange Version 2, Internet Key Exchange Version 2 CLI Constructs, Tutorial: Setting up a certificate-based IKEv2 VPN connection (RSA)

The kind of API that is used with Cisco DNA Center to provision SSIDs, QoS policies, and update software versions on switches is the Intent API. The Intent API is a category of APIs that allows users to express their desired network outcomes or intents, such as creating a site, adding a device, or deploying a network profile. The Intent API then translates these intents into specific network configurations and commands, and applies them to the relevant network devices and services. The Intent API simplifies and automates the network provisioning and management process, and enables users to focus on the business objectives rather than the technical details. Some examples of Intent APIs are:

Site Management API: This API allows users to create, update, delete, and retrieve sites and buildings in Cisco DNA Center. A site is a logical grouping of network devices and services that share common characteristics, such as location, policies, or functions. A site can have one or more buildings, and a building can have one or more floors. Sites are used to organize and manage the network hierarchy and topology.

Network Settings API: This API allows users to configure and manage network-wide settings, such as global credentials, network discovery, IP address pools, DHCP and DNS servers, and SNMP settings. These settings are applied to all network devices and services that are managed by Cisco DNA Center.

Network Profile API: This API allows users to create, update, delete, and retrieve network profiles in Cisco DNA Center. A network profile is a collection of network settings and policies that define how a network segment or service should operate, such as SSIDs, QoS policies, security policies, and device roles. Network profiles are used to standardize and simplify the network configuration and deployment process, and to ensure consistency and compliance across the network.

Software Image Management API: This API allows users to manage the software images and versions of network devices that are managed by Cisco DNA Center. Users can import, export, delete, and retrieve software images, as well as assign them to network devices or device groups. Users can also schedule and monitor software image updates, and view the software image compliance status of network devices.

 The Decrypt for Application Detection feature within the WSA Decryption options enhances the ability of AsyncOS to detect HTTPS applications. The HTTPS Proxy can decrypt HTTPS connections to web applications. This allows the Application Visibility and Control (AVC) engine to more accurately detect and block web applications that use HTTPS. This feature can help improve the security and performance of the network by identifying and controlling the usage of web applications that may consume bandwidth, pose security risks, or violate compliance policies.

 The RADIUS CoA feature supports the IETF attribute 24 State, which is used to identify the session for which the CoA request is intended. The State attribute is sent by the device in the Access-Accept message and must be echoed back by the RADIUS server in the CoA-Request message. The other attributes are not supported for the RADIUS CoA feature.

To understand the concept of RADIUS CoA and the supported attributes, you can refer to the following sections of the source book:

Section 1.1.2: Describe the concepts of network security

Section 1.1.2.6: Describe the concepts of RADIUS CoA

Section 1.1.2.7: Describe the concepts of supported IETF attributes

 DoS attacks are categorized as flood attacks or crash attacks. Flood attacks are the more common form of DoS attacks. They occur when the attacked system is overwhelmed by large amounts of traffic that the server is unable to handle. The system eventually stops. Some examples of flood attacks are ICMP flood, SYN flood, and UDP flood. Crash attacks are less frequent and they exploit flaws in the targeted system. The result is that the system crashes. Some examples of crash attacks are Ping of Death, Teardrop, and Land. References:

What is a denial-of-service (DoS) attack? | Cloudflare

What is a Denial of Service (DoS) attack? | Norton

What is a Denial of Service (DoS) Attack? | Cobalt

What is a denial of service attack (DoS) - Palo Alto Networks

Asymmetric encryption, also known as public-key cryptography, is a type of encryption that uses a pair of keys to encrypt and decrypt data. The pair of keys includes a public key, which can be shared with anyone, and a private key, which is kept secret by the owner. In asymmetric encryption, the sender uses the recipient’s public key to encrypt the data. The recipient then uses their private key to decrypt the data. This approach allows for secure communication between two parties without the need for both parties to have the same secret key. RSA is one of the most commonly used asymmetric encryption algorithms. It is based on the mathematical problem of factoring large numbers, which is believed to be hard to solve. RSA stands for Rivest-Shamir-Adleman, the names of the three inventors of the algorithm. RSA can be used for both encryption and digital signatures. To generate an RSA key pair, the following steps are performed:

Choose two large prime numbers, p and q, and compute their product, n = pq. This is called the modulus.

Choose a small number, e, that is relatively prime to (p-1)(q-1). This is called the public exponent.

Compute a number, d, that satisfies the equation ed ≡ 1 (mod (p-1)(q-1)). This is called the private exponent.

The public key is (n, e) and the private key is (n, d).

To encrypt a message, m, with the public key (n, e), the following formula is used:

c = m^e mod n

To decrypt a ciphertext, c, with the private key (n, d), the following formula is used:

m = c^d mod n

References :=

[Implementing and Operating Cisco Security Core Technologies (SCOR) v1.0], Module 3: VPN Technologies, Lesson 3.1: Site-to-Site VPNs, Topic 3.1.2: IPsec VPNs

What is Asymmetric Encryption? - GeeksforGeeks

What is asymmetric encryption? | Asymmetric vs. symmetric … - Cloudflare

Northbound APIs are the link between the applications and the SDN controller. The applications can tell the network what they need (data, storage, bandwidth, and so on) and the network can deliver those resources, or communicate what it has. These APIs support a wide variety of applications, such as load balancers, firewalls, orchestration platforms, and automation stacks. Northbound APIs also enable the applications to use the controller’s capabilities to program flows into the network devices using the southbound interface. Northbound APIs are usually RESTful APIs that use HTTP methods to exchange data in JSON or XML formats12.

OpenFlow is not a northbound API protocol, but a southbound API protocol that defines the communication between the SDN controller and the network switches or routers. OpenFlow allows the controller to manipulate the forwarding behavior of the switches or routers by sending commands and receiving events3 .

NETCONF is not a northbound API protocol, but a network management protocol that can be used as a southbound API protocol to configure and monitor network devices. NETCONF uses XML to encode data and remote procedure calls (RPCs) to exchange messages between the controller and the network devices . References := 1: What are SDN Northbound APIs (and SDN Rest APIs)? - SDxCentral 2: SDN North-bound and South-bound APIs and Interfaces 3: OpenFlow - Wikipedia : OpenFlow - SDxCentral : NETCONF - Wikipedia : NETCONF Protocol - Cisco

1sdxcentral.com2computernetworkingnotes.com3examguides.com
