200-301 Exam Dumps - Cisco Certified Network Associate
Refer to the exhibit. An LACP EtherChannel between two directly connected switches is in the configuration process.
Which command must be configured on switch SW2’s Gi0/1-2 interfaces to establish the channel to SW1?
Refer to the exhibit.
Which configuration is needed to configure a WLAN with WPA2 only and with a password that is 63 characters long?
Refer to the exhibit. A network engineer is adding another physical interface as a new member to the existing Port-Channel1 bundle.
Which command set must be configured on the new interface to complete the process?
What is the total number of users permitted to simultaneously browse the controller management pages when using the AireOS GUI?
Refer to the exhibit. Which configuration enables SW2 to establish an LACP EtherChannel?
IP connectivity between the three routers is configured. OSPF adjacencies must be established.
1. Configure R1 and R2 Router IDs using the interface IP addresses from the link that is shared between them.
2. Configure the R2 links with a max value facing R1 and R3. R2 must become the DR. R1 and R3 links facing R2 must remain with the default OSPF configuration for DR election. Verify the configuration after clearing the OSPF process.
3. Using a host wildcard mask, configure all three routers to advertise their respective Loopback1 networks.
4. Configure the link between R1 and R3 to disable their ability to add other OSPF routers.
