Temporal resolution is improved by increasing the frame rate. One way to increase the frame rate is by decreasing the packet size (also known as ensemble length) in color Doppler imaging. The packet size refers to the number of pulses used to determine the Doppler shift at each location. A smaller packet size means fewer pulses are required, which allows for quicker data acquisition and thus a higher frame rate. Increasing the field of view, decreasing transmit frequency, and increasing line density would all decrease the frame rate and thus degrade temporal resolution.

Comprehensive and Detailed Explanation From Exact Extract:

When the ultrasound beam travels through a structure that attenuates less than surrounding tissues, more energy reaches structures located deeper. This results in stronger echo signals from those deeper structures, which is visualized as a brightening or enhancement distal to the structure. This is referred to as acoustic enhancement or posterior enhancement.

Official sonography instrumentation reference states:

“Enhancement occurs as a result of reduced attenuation of the sound beam as it passes through fluid-filled or weakly attenuating structures, causing reflectors distal to the structure to appear more echogenic than normal.”

Therefore, the correct answer is B: Enhancement.

Comprehensive and Detailed Explanation From Exact Extract:

Higher frequency transducers provide better axial resolution due to their shorter wavelengths and spatial pulse lengths. This allows finer detail when imaging superficial structures where penetration is not a concern.

According to sonography instrumentation reference:

“Higher frequencies result in shorter pulse lengths, improving axial resolution and making them ideal for superficial imaging.”

Therefore, the correct answer is D: Improved axial resolution.

—

Comprehensive and Detailed Explanation From Exact Extract:

The key advantage of pulsed wave Doppler is range resolution, meaning the operator can select a specific depth (sample volume) for measuring velocities. Continuous wave Doppler does not provide this capability, as it samples velocities along the entire beam path.

According to sonography instrumentation reference:

“Pulsed wave Doppler allows selection of sample volume depth, providing range resolution which continuous wave Doppler lacks.”

Therefore, the correct answer is B: Ability to select sample depth.

105

What adjustment is needed to optimize the image below?

A close-up of a medical scan Description automatically generated

A. Increase wall filter

B. Steer the box

C. Decrease scale

D. Raise focal zone

Answer: B

Comprehensive and Detailed Explanation From Exact Extract:

In the displayed image, the color box is not aligned parallel to the direction of blood flow in the vessel. Color Doppler is angle-dependent; when the color box is not properly steered to align with flow, the Doppler shift is reduced, and less color filling occurs. Steer the box to align the ultrasound beam more parallel to flow to maximize Doppler shift and improve color filling.

According to sonography instrumentation reference:

“Steering the color box aligns the Doppler beam with blood flow direction, optimizing the Doppler angle and improving flow visualization.”

Therefore, the correct answer is B: Steer the box.

—

—

Attenuation refers to the reduction in the intensity of the ultrasound beam as it travels through tissue. Higher frequency ultrasound beams experience more attenuation because they are absorbed and scattered more than lower frequency beams. This is due to the fact that higher frequency waves have shorter wavelengths and interact more with the small particles in tissues, causing greater energy loss.

Comprehensive and Detailed Explanation From Exact Extract:

Axial resolution is determined by the spatial pulse length (SPL). A longer SPL means that structures closer together along the beam axis are more likely to overlap in the returning echoes, degrading axial resolution.

According to sonography instrumentation reference:

“Axial resolution is inversely related to spatial pulse length. Increasing SPL worsens the ability to distinguish closely spaced structures along the beam axis.”

Therefore, the correct answer is B: Degraded axial resolution.

—

86

Based on the table in this image, what is the sensitivity?

A white square with black numbers and a white square with black numbers Description automatically generated

A. 32/33

B. 32/35

C. 45/46

D. 45/48

Answer: B

Comprehensive and Detailed Explanation From Exact Extract:

Sensitivity measures the test's ability to correctly identify true positives. It is calculated using the formula:

Sensitivity = True Positives / (True Positives + False Negatives)

From the table:

True Positives (TP) = 32 (Noninvasive test positive & Gold Standard positive)

False Negatives (FN) = 3 (Noninvasive test negative but Gold Standard positive)

Thus:

Sensitivity = 32 / (32 + 3)

Sensitivity = 32 / 35

According to sonography instrumentation reference:

“Sensitivity represents the proportion of actual positive cases correctly identified by the test.”

Therefore, the correct answer is B: 32/35.

At what Doppler angle to flow is the maximum Doppler shift frequency acquired?

A. 90 degrees

B. 60 degrees

C. 30 degrees

D. 0 degrees

Answer: D

Comprehensive and Detailed Explanation From Exact Extract:

The Doppler equation shows that the frequency shift is proportional to the cosine of the Doppler angle. The maximum value of cosine (cos 0° = 1) occurs at 0 degrees — meaning the beam is parallel to flow. At this angle, the full velocity component is measured.

According to sonography instrumentation reference:

“The maximum Doppler shift is obtained when the ultrasound beam is parallel (0 degrees) to blood flow.”

Therefore, the correct answer is D: 0 degrees.

—

Narrowing the field of view reduces the number of scan lines that need to be processed per frame. This allows the ultrasound system to maintain or even increase the frame rate without compromising temporal resolution. Temporal resolution, which refers to the system's ability to depict motion accurately, is directly related to the frame rate. Reducing the field of view ensures fewer lines are needed to create each image, thus preserving the frame rate and temporal resolution.

ARDMS Sonography Principles and Instrumentation guidelines

Kremkau, F. W. (2015). Diagnostic Ultrasound: Principles and Instruments.

Comprehensive and Detailed Explanation From Exact Extract:

The primary advantage of pulsed-wave Doppler is its ability to provide range resolution. This means the operator can select a specific depth (sample volume) from which Doppler signals are acquired, allowing precise localization of blood flow velocities.

According to sonography instrumentation reference:

“Pulsed-wave Doppler allows for range resolution, enabling velocity measurements at a specific depth along the ultrasound beam path.”

Continuous-wave Doppler does not have range resolution, as it measures velocities along the entire beam path.

Therefore, the correct answer is C: Range resolution.

—
