OSPF neighbors not forming adjacency and stuck in the 2WAY state typically indicates that the interface is set to passive mode, preventing OSPF Hello packets from being sent or received on that interface.

Removing passive mode on VLAN 182 allows OSPF Hello messages to be exchanged and adjacency to form.

Options involving network type or costs do not affect adjacency states related to passive interfaces.

The max-metric router-lsa on-startup affects LSA advertisements, not adjacency formation.

Therefore, the fix is to configure no passive-interface vlan182.

For BGP in a multi-homed configuration advertising public IP blocks, the AS number should be a valid public AS number allocated by the regional internet registry (RIR). Numbers in the private AS range (64512–65534) are not suitable for public Internet announcements.

63472 falls in the public AS range (16-bit AS numbers below 64512).

64813, 65535, and 65218 are in the private or reserved range.

Therefore, 63472 is an example of a suitable public AS number.

Backing up the switch configuration to a remote Linux SFTP server requires using the copy command with the correct protocol (SFTP in this case), username, server IP, filename, and optionally the VRF to route management traffic.

Option A uses SCP and vrf default but the question mentions SFTP server, so SFTP protocol should be used.

Option B is a server-side command (not the switch).

Option C correctly uses copy startup-config sftp://user@192.168.1.100/switch_config.cfg vrf mgmt which backs up the startup-config via SFTP using the management VRF.

Option D is also a server-side command.

Using vrf mgmt is required because the management IP is in a separate VRF on CX switches.

In a high-security " Colorless Ports " environment using AOS-CX, we often run both 802.1X (Dot1x) and MAC Authentication (MAC-auth) on the same port to handle a mix of corporate laptops and " dumb " IoT devices (printers, cameras).

The Default Behavior: By default, the switch usually attempts 802.1X first. When a device like a printer is plugged in, it does not have an 802.1X " supplicant " to respond to the switch ' s EAPOL-Request packets. The switch will wait for a series of timeouts and retries (EAPOL timeouts) before it gives up on 802.1X and moves on to the next method (MAC-auth). This waiting period is what causes the " few minutes " delay the user is experiencing.

Auth-Precedence vs. Auth-Priority:

Auth-Precedence: This defines the order in which the switch attempts the authentication methods.

Auth-Priority: This defines which method " wins " if multiple methods succeed (relevant for a PC that might trigger both).

The Solution: By changing the auth-precedence to mac-auth dot1x, the switch immediately captures the device ' s MAC address and sends it to the RADIUS server (like Aruba ClearPass) for authentication.

For a printer, MAC-auth succeeds immediately, and the port is authorized without waiting for 802.1X timeouts.

For a corporate laptop, MAC-auth happens first (granting basic or initial access), and then the 802.1X process can trigger immediately after to provide higher-level " User " access.

Why other options are incorrect:

Option A: Disabling 802.1X removes the security for corporate devices on those ports; it is not a " secure configuration " maintenance.

Option B: Increasing the timeout would make the delay worse , not better.

Option D: There is no specific " MAC auth start value " timer in AOS-CX that would solve a multi-minute delay caused by the 802.1X failure wait.

CLI Example:

Bash

interface 1/1/1

aaa authentication port-access auth-precedence mac-auth dot1x

When managing a network through HPE Aruba Networking Central , administrators have access to specialized reporting tools designed for lifecycle management and expansion planning.

Purpose of the Switch Capacity Planning Report: This specific report is engineered to give a clear overview of physical and electrical headroom within the switching infrastructure. When preparing to add new Access Points (APs), two variables are critical:

Port Density: The report identifies the number of available (unused) ports across various speeds (1GbE, 2.5GbE, 5GbE, etc.).

PoE Budgeting: High-performance APs (such as Wi-Fi 6E or Wi-Fi 7 models) require significant Power over Ethernet (PoE) wattage (PoE+ or UPoE). The report calculates the Total PoE Budget vs. the Currently Allocated PoE , allowing you to see if the switch power supplies can handle the additional load.

Evaluating Other Options:

Option A (Infra Inventory): This report focuses on asset management. it provides details like serial numbers, MAC addresses, hardware models, and firmware versions. It does not provide real-time or historical port usage or PoE consumption data.

Option C (Network): This is a broader summary report that typically focuses on connectivity, client counts, and overall network health rather than specific hardware resource limits.

Option D (Resource Utilization): While this report is useful, it generally focuses on System Resources such as CPU usage, Memory (RAM) consumption, and temperature sensors rather than physical port availability or PoE power budgets.

Best Practice: In an Aruba Central environment, running the Switch Capacity Planning report before a hardware refresh or expansion is a mandatory step to avoid " PoE starvation " or physical port shortages during the installation phase.

In the study of BGP (Border Gateway Protocol) for AOS-CX, understanding the differences between Internal BGP (iBGP) and External BGP (eBGP) is fundamental to the ACP-S certification.

eBGP Peering Definition: eBGP occurs when two BGP neighbors reside in different Autonomous Systems. In this scenario, the local switch is in AS 65010 and the neighbor is in AS 65100 .

The " Directly Connected " Requirement: By default, BGP assumes that eBGP neighbors are directly connected (physically connected or on the same subnet). This is because eBGP packets are sent with a Time-to-Live (TTL) of 1 . If the neighbor is more than one hop away (for example, peering via loopback interfaces without additional configuration), the packet will expire before reaching the neighbor, and the session will not establish.

Terminology Note: The term " directory connected " in the question is a common typographical error in exam materials for " directly connected. " In the context of eBGP peering, being directly connected is the default requirement to ensure the TTL 1 packet reaches the peer. If you were peering with a non-directly connected device, you would need to manually configure ebgp-multihop.

Analysis of Other Options:

Option A: This is incorrect as it uses a random AS number (65001) that does not match the local or neighbor AS provided in the prompt.

Option B: Route Reflectors are a solution used exclusively in iBGP to solve the split-horizon rule (which dictates that a prefix learned from an iBGP peer cannot be advertised to another iBGP peer). Route reflectors are never used for standard eBGP sessions.

Option D: While AOS-CX requires you to enter the address-family ipv4 unicast context to activate a neighbor, the keyword " internal " is not a valid address-family type in the AOS-CX BGP syntax for this purpose.

Key Practice Tip: When configuring BGP on AOS-CX, always remember that after defining the neighbor x.x.x.x remote-as, you must enter the address-family context and use the neighbor x.x.x.x activate command for the session to transition to the " Established " state.

The error message " Invalid input: interface " typically appears if the switch is managed by HPE Aruba Central, which restricts CLI interface configuration to prevent configuration drift. When managed externally, certain commands are disabled or locked.

Password recovery mode or authorization enabled would not cause this error.

Manager context is not a concept in Aruba CX CLI.

In AOS-CX QoS architecture, the switch uses a scheduler to determine which hardware queues receive service. A common best practice is to use a Hybrid Queuing Model .

Strict Priority (SP) and Starvation: By default, if a queue is set to Strict Priority (usually Queue 7 for voice), the switch will service that queue exclusively as long as it has data. If the high-priority traffic is sustained (due to a burst or a misconfiguration/attack), the lower-priority queues (Queues 0–5) will never be serviced. This is known as starvation .

The Role of Shaping: To prevent an SP queue from monopolizing the entire link bandwidth, you can apply a shaper to that specific high-priority queue. A shaper sets a maximum bandwidth limit (in kbps or as a percentage) that the queue is allowed to consume.

Mechanism: By shaping Queue 7, even if it has a constant stream of traffic, it will be " throttled " once it hits the shaper limit. This forced " quiet time " allows the scheduler to move down and service the lower-priority queues using DWRR (Deficit Weighted Round Robin) logic, ensuring that data traffic (like web or email) is not completely dropped.

Evaluating Other Options:

Option A: You can only apply one queuing profile per interface in AOS-CX.

Option B: Replacing SP with DWRR entirely would solve starvation, but it would remove the low-latency guarantee required for Voice traffic.

Option D: " Weight " applies only to DWRR/WFQ queues. SP queues do not have a weight because they are always " first in line " by definition.
