300-815 Exam Dumps - Implementing Cisco Advanced Call Control and Mobility Services (CLACCM)

Go to page:
Question # 41

A single site reports that when they dial select numbers, the call connects, but they do not get audio. The administrator finds that the calls are not routing out of the normal gateway but out of another site's gateway due to a TEHO configuration. What is the next step to diagnose and solve the issue?

A.

Verify that IP routing is correct between the gateway and the IP phone.

B.

Verify that the route pattern is not blocking calls to the destination number.

C.

Verify that the dial peer of the gateway has the correct destination pattern configured.

D.

Verify that the route pattern has the correct calling-party transformation mask

Full Access
Question # 42

Which configuration element of a hunt group allows for changing Calling Party Transformations settings?

A.

line group

B.

hunt pilot

C.

route group

D.

hunt list

Full Access
Question # 43

Refer to the exhibit. A standard local route group is configured for long-distance calls. Calls from building A succeed, but calls from building B fail. On the system. Each building has is own device pool. The DNA tool is used to test the configuration. How is this issue resolved?

A.

Change the partition of the route pattern

B.

Add a sip trunk inside route group Standard Local Route Group.

C.

Modify the route pattern to add a prefix of 91

D.

Add a local route group on the device pool configuration.

Full Access
Question # 44

An engineer is configuring a Cisco UCM solution. The requirements state that some users in one location will receive calls from a number during work hours 09AM to 5PM, and another group will get the calls from the same number outside this defined timeslot. Users will also change the outgoing number when reaching out to customers based on the same time-of-day routing rules. Which feature is needed to allow for this type of configuration?

A.

partitions

B.

route groups

C.

route lists

D.

CSS

Full Access
Question # 45

Refer to the exhibit. An administrator is trying to test outbound calls toward the ITSP but cannot complete the call and receives a SIP error. ITSP is consulted, and the issue is that the ANI that is being sent is not the DID provided 8005532447. Which configuration change sends the correct ANI on the INVITE sent to ITSP to fix the error?

A.

voice class sip-profiles 2

request INVITE sip-header To modify “sip:(.*)@” sip:8005532447@

B.

voice translation-rule 3

rule 1/.*/ /8005532447/

C.

voice class sip-profiles 1

request INVITE sip-header Diversion modify “sip:(.*)@” “sip:8005532447@”

D.

voice translation-rule 4

rule 1/^.*\(8005532447\)/ /\1/

Full Access
Question # 46

A company was looking at the IT charges and saw many long-distance and international calls primarily to sites in North America and around the world. The administrator wants to optimize the PSTN expense. Which dial plan configuration reduces PSTN connectivity charges by using the IP network to bring the egress point to the PSTN as close as possible to the called number?

A.

translation patterns

B.

tail end hop off

C.

client matter codes

D.

dial rules

Full Access
Question # 47

A Collaboration engineer is implementing call processing capabilities on the Cisco UCM and needs to configure Call Queuing to place callers in a queue until hunt members are available to answer them. Which action must be completed before this feature can be configured?

A.

Configure Hunt Pilot Queuing.

B.

Service the Cisco IP Voice Media Streaming (IPVMS) application.

C.

Configure Music On Hold.

D.

Configure announcements.

Full Access
Question # 48

Refer to the exhibit.

An administrator received reports that users do not hear a ringback when they dial specific external numbers. For example, the Cisco Unified Border Element receives a delayed offer invite from Cisco UCM and responds with the 183 session progress in the exhibit. Assume that thePSTN is responsible for generating ringback in these problematic scenarios. Which action resolves the issue?

A.

Enable early media on the appropriate SIP trunk on Cisco UCM.

B.

Edit the configuration for SIP ReMXX Options in the appropriate SIP profile on Cisco UCM to Send PRACK if 1xx Contains SDP.

C.

On Cisco Unified Border Element: voice service voip sip

Re1xx require 100rel

D.

On Cisco Unified Border Element: voice service voip sip

Re1xx disable 100rel

Full Access
