Question # 145

Drag and drop the DHCP messages from the left onto the correct uses on the right.

Full Access

Answer:

Explanation:

DHCPACK

The server-to-client communication with configuration parameters, including committed network address.

DHCPINFORM

The client-to-server communication, asking for only local configuration parameters that the client already has externally configured as an address.

DHCPNAK

The server-to-client communication, refusing the request for configuration parameter.

DHCPDECLINE

The client-to-server communication, indicating that the network address is already in use

[Reference: https://www.cisco.com/c/en/us/support/docs/ip/dynamic-address-allocation-resolution/27470-100.html, DHCPINFORM: If a client has obtained a network address through some other means or has a manually configured IP address, a client workstation may use a DHCPINFORM request message to obtain other local configuration parameters, such as the domain name and Domain Name Servers (DNSs). DHCP servers receiving a DHCPINFORM message construct a DHCPACK message with any local configuration parameters appropriate for the client without allocating a new IP address. This DHCPACK will be sent unicast to the client., DHCPNAK: If the selected server is unable to satisfy the DHCPREQUEST message, the DHCP server will respond with a DHCPNAK message. When the client receives a DHCPNAK message, or does not receive a response to a DHCPREQUEST message, the client restarts the configuration process by going into the Requesting state. The client will retransmit the DHCPREQUEST at least four times within 60 seconds before restarting the Initializing state., DHCPACK: After the DHCP server receives the DHCPREQUEST, it acknowledges the request with a DHCPACK message, thus completing the initialization process., DHCPDECLINE: The client receives the DHCPACK and will optionally perform a final check on the parameters. The client performs this procedure by sending Address Resolution Protocol (ARP) requests for the IP address provided in the DHCPACK. If the client detects that the address is already in use by receiving a reply to the ARP request, the client will send a DHCPDECLINE message to the server and restart the configuration process by going into the Requesting state., , Reference:, https://www.cisco.com/c/en/us/support/docs/ip/dynamic-address-allocation-resolution/27470-100.html, , , ]

Question # 146

Which attribute eliminates LFAs that belong to protected paths in situations where links in a network are connected through a common fiber?

shared risk link group-disjoint

linecard-disjoint

lowest-repair-path-metric

interface-disjoint

Full Access

Question # 147

Drag and drop the SNMP attributes in Cisco IOS devices from the left onto the correct SNMPv2c or SNMPV3 categories on the right.

Full Access

Question # 148

A network engineer needs to verify IP SLA operations on an interface that shows on indication of

excessive traffic.

Which command should the engineer use to complete this action?

show frequency

show track

show reachability

show threshold

Full Access

Question # 149

Refer to the following output:

Router#show ip nhrp detail

10.1.1.2/8 via 10.2.1.2, Tunnel1 created 00:00:12, expire 01:59:47

TypE. dynamic, Flags: authoritative unique nat registered used

NBMA address: 10.12.1.2

What does the authoritative flag mean in regards to the NHRP information?

It was obtained directly from the next-hop server.

Data packets are process switches for this mapping entry.

NHRP mapping is for networks that are local to this router.

The mapping entry was created in response to an NHRP registration request.

The NHRP mapping entry cannot be overwritten.

Full Access

Question # 150

Refer to the exhibit.

AAA server 10.1.1.1 is configured with the default authentication and accounting settings, but the switch cannot communicate with the server Which action resolves this issue?

Match the authentication port

Match the accounting port

Correct the timeout value.

Correct the shared secret.

Full Access
