SPLK-1002 Exam Dumps - Splunk Core Certified Power User Exam

The transaction command is a search command that creates a single event from a group of events that share some common characteristics. The transaction command can group events based on fields, time, or both. The transaction command can also create some additional fields for each transaction, such as duration, eventcount, startime, etc. The transaction command does not group a set of transactions based on time, but rather groups a set of events into a transaction based on time. The transaction command does not separate two events based on one or more values, but rather joins multiple events based on one or more values. The transaction command does not return the number of credit card transactions found in the event logs, but rather creates transactions from the events that match the search criteria.

The search below groups events by two or more fields (clientip and host), creates transactions with start and end constraints (maxspan=30s and maxpause=5s), and calculates the duration of each transaction.

index=main | transaction clientip host maxspan=30s maxpause=5s

The search does the following:

It filters the events by the index main, which is a default index in Splunk that contains all data that is not sent to other indexes.

It uses the transaction command to group events into transactions based on two fields: clientip and host. The transaction command creates new events from groups of events that share the same clientip and host values.

It specifies the start and end constraints for the transactions using the maxspan and maxpause arguments. The maxspan argument sets the maximum time span between the first and last events in a transaction. The maxpause argument sets the maximum time span between any two consecutive events in a transaction. In this case, the maxspan is 30 seconds and the maxpause is 5 seconds, meaning that any transaction that has a longer time span or pause will be split into multiple transactions.

It creates some additional fields for each transaction, such as duration, eventcount, startime, etc. The duration field shows the time span between the first and last events in a transaction.

The Field Extractor (FX) allows you to use regular expressions (regex) to extract fields from your events using a graphical interface or by manually editing the regex2. When you use the FX to perform a regex field extraction, you can use the require option to specify a string that must be present in an event for it to be included in the extraction2. This way, you can filter out events that do not contain the required string and focus on the events that are relevant for your extraction2. Therefore, option D is correct, while options A, B and C are incorrect.

A chart is a graphical representation of your search results that shows the relationship between two or more fields2. You can display a chart in stack mode by changing the Stack Mode option in the Format menu2. Stack mode allows you to stack multiple series on top of each other in a chart to show the cumulative values of each series2. Therefore, option C is correct, while options A, B and D are incorrect because they are not ways to display a chart in stack mode.

The transaction command is used to group events into transactions based on some common characteristics, such as fields, time, or both. The transaction command can also specify start and end constraints for the transactions, such as a field value that indicates the beginning or the end of a transaction. The stats command is used to calculate summary statistics on the events, such as count, sum, average, etc. The stats command cannot group events based on start and end constraints, but only on fields or time buckets. Therefore, the transaction command should be used instead of the stats command when you need to group events based on start and end constraints.

The search string below returns events from the data model named Application_State.

| datamodel Application_State All_Application_State search

The search string does the following:

It uses the datamodel command to access a data model in Splunk. The datamodel command takes two arguments: the name of the data model and the name of the dataset within the data model.

It specifies the name of the data model as Application_State. This is a predefined data model in Splunk that contains information about web applications.

It specifies the name of the dataset as All_Application_State. This is a root dataset in the data model that contains all events from all child datasets.

It uses the search command to filter and transform the events from the dataset. The search command can use any search criteria or command to modify the results.

Therefore, the search string returns events from the data model named Application_State.
