SPLK-1002 Exam Dumps - Splunk Core Certified Power User Exam

In Splunk, the NOT operator is used to exclude events from your search results. The search index=network NOT StatusCode=200 will return all events in the ‘network’ index where the StatusCode is not 200. This includes events where the StatusCode field is present and has a value other than 200, as well as events where the StatusCode field is not present at all.

The correct answer is D. eval.

A calculated field is a field that is added to events at search time by using an eval expression. A calculated field can use the values of two or more fields that are already present in the events to perform calculations. A calculated field can be defined with Splunk Web or in the props.conf file. They can be used in searches, reports, dashboards, and data models like any other extracted field1.

A calculated field is a shortcut for performing repetitive, long, or complex transformations using the eval command. The eval command is used to create or modify fields by using expressions. The eval command can perform mathematical, string, date and time, comparison, logical, and other operations on fields or values2.

For example, if you want to create a new field named total that is the sum of two fields named price and tax, you can use the eval command as follows:

| eval total=price+tax

However, if you want to use this new field in multiple searches, reports, or dashboards, you can create a calculated field instead of writing the eval command every time. To create a calculated field with Splunk Web, you need to go to Settings > Fields > Calculated Fields and enter the name of the new field (total), the name of the sourcetype (sales), and the eval expression (price+tax). This will create a calculated field named total that will be added to all events with the sourcetype sales at search time. You can then use the total field like any other extracted field without writing the eval expression1.

The other options are not correct because they are not related to calculated fields. These options are:

A. transaction: This command is used to group events that share some common values into a single record, called a transaction. A transaction can span multiple events and multiple sources, and can be useful for correlating events that are related but not contiguous3.

B. lookup: This command is used to enrich events with additional fields from an external source, such as a CSV file or a database. A lookup can add fields to events based on the values of existing fields, such as host, source, sourcetype, or any other extracted field.

C. stats: This command is used to calculate summary statistics on the fields in the search results, such as count, sum, average, etc. It can be used to group and aggregate data by one or more fields.

The eval command is used to create new fields or modify existing fields based on an expression2. The eval command can perform various actions such as calculations, conversions, string manipulations and more2. One of the actions that the eval command can perform is to create or replace an existing field with a new value based on an expression2. For example, | eval status=if(status="200","OK","ERROR") will create or replace the status field with either OK or ERROR depending on the original value of status2. Therefore, option B is correct, while options A, C and D are incorrect because they are not actions that the eval command can perform.

The statement that fields extracted using the Field Extractor persist as knowledge objects is true. The Field Extractor (FX) is a graphical tool that allows you to extract fields from raw events using regular expressions or delimiters. The fields extracted by the FX are saved as knowledge objects that can be used in future searches or shared with other users.

The Splunk Common Information Model (CIM) add-on is a Splunk app that contains data models to help you normalize data from different sources and formats. The CIM add-on defines a common and consistent way of naming and categorizing fields and events in Splunk. This makes it easier to correlate and analyze data across different domains, such as network, security, web, etc. The CIM add-on does not use machine learning to normalize data, but rather relies on predefined field names and values. The CIM add-on does not contain dashboards that show how to map data, but rather provides documentation and examples on how to use the data models. The CIM add-on is not automatically installed in a Splunk environment, but rather needs to be downloaded and installed from Splunkbase.

 There are several ways to access the field extractor. The option that automatically identifies data type, source type, and sample event is Fields sidebar > Extract New Field. The field extractor is a tool that helps you extract fields from your data using delimiters or regular expressions. The field extractor can generate a regex for you based on your selection of sample values or you can enter your own regex in the field extractor. The field extractor can be accessed by using various methods, such as:

Fields sidebar > Extract New Field: This is the easiest way to access the field extractor. The fields sidebar is a panel that shows all available fields for your data and their values. When you click on Extract New Field in the fields sidebar, Splunk will automatically identify the data type, source type, and sample event for your data based on your current search criteria. You can then use the field extractor to select sample values and generate a regex for your new field.

Event Actions > Extract Fields: This is another way to access the field extractor. Event actions are actions that you can perform on individual events in your search results, such as viewing event details, adding to report, adding to dashboard, etc. When you click on Extract Fields in the event actions menu, Splunk will use the current event as the sample event for your data and ask you to select the source type and data type for your data. You can then use the field extractor to select sample values and generate a regex for your new field.

Settings > Field Extractions > New Field Extraction: This is a more advanced way to access the field extractor. Settings is a menu that allows you to configure various aspects of Splunk, such as indexes, inputs, outputs, users, roles, apps, etc. When you click on New Field Extraction in the Settings menu, Splunk will ask you to enter all the details for your new field extraction manually, such as app context, name, source type, data type, sample event, regex, etc. You can then use the field extractor to verify or modify your regex for your new field.

Field aliases can only be applied after fields have been extracted .

Extract: “Field extraction occurs before field aliasing in the search-time data processing order. Field aliases depend on extracted field names to function.”

Thus, fields must first be extracted before any alias can be assigned.
