H35-211_V2.5 Exam Dumps - HCIP-Access V2.5

This statement is wrong. In U2000, network elements (NEs) can be added by multiple methods, including batch addition/import and automatic discovery, not just one-by-one during a live access session. U2000 supports template-based onboarding and batch operations to improve efficiency for large-scale deployments.

Huawei digitmap syntax uses x to represent any single digit 0–9. To match a 7-digit number starting with 7727, the correct pattern is 7727xxx.

A adds an unrelated rule 7726. and uses . incorrectly as a wildcard; not recommended.

B uses 772. (invalid for the intended match) plus 7727xxx; the first part is improper.

C matches only the 4-digit string 7727.

D contains 7727xxx (correct) and an additional 7727 rule; although the extra rule is unnecessary, it does not prevent correct matching.

IP multicast is designed for one-to-many delivery, allowing a single source stream to be replicated in the network only where branching is required. Compared with sending multiple unicast copies, multicast significantly reduces bandwidth consumption on shared links and provides efficient point-to-multipoint distribution. This is the core rationale for using multicast in video/TV services on campus and access networks.

Huawei QoS describes PQ (Priority Queuing) as the strict-priority scheduler ensuring that high-priority queues are served first before lower-priority queues. WRR/DRR/RR are weighted or round-robin modes intended for fair sharing and do not guarantee strict preemption for latency-sensitive traffic. Therefore, PQ is selected for higher-priority services (e.g., voice, control).

In NGN architectures, services (voice, video, data) converge over a packet-based backbone. The core switching layer provides the unified transport using IP/MPLS and related QoS mechanisms, delivering high reliability and large-capacity switching for all upper-layer services. The control and management layers orchestrate services, while the edge/access layer aggregates users—but the packet-based integrated transmission platform itself is the role of the core.

A mismatch between the service-profile’s user-port configuration and the ONT’s actual port capacity does not disable all services. Ports beyond the ONT’s capability remain inactive/unused, while valid ports with correct service bindings continue to work. Service availability depends on the consistency of applied profiles and actual hardware resources, not on a complete shutdown.

According to IEEE 802.3av wavelength planning adopted by Huawei 10G-EPON, downstream uses 1577 nm and 10G upstream uses 1270 nm. In asymmetric coexistence, 1G-EPON upstream uses 1310 nm, but for 10G-EPON upstream specifically the wavelength is 1270 nm. Therefore the correct upstream wavelength for 10G-EPON is 1270 nm.
