In an OSPF broadcast or NBMA network with at least two routers, one router must act as the DR (Designated Router), and another as the BDR (Backup Designated Router) to ensure efficient communication and reduce the number of adjacencies. This is a requirement for OSPF operation in such network types ​.

ï‚· ACL Modification

Named ACLs can be modified after their creation. Unlike numbered ACLs, named ACLs provide greater flexibility for editing individual rules without deleting the entire ACL.

Therefore, the statement is incorrect.

ï‚· HCIP-Datacom-Core Reference

The flexibility and editability of named ACLs are discussed in the ACL configuration sections​​.

In the given topology, the route from R4 to 10.0.2.2/32 traverses R3, which performs route leaking from Level-2 to Level-1. The cost is calculated as follows: R4 to R3 (40) + R3 to R2 (10) + R2 to the destination (30), resulting in a total cost of 80 ​.

Access Control Lists (ACLs) can be classified into several types, including Basic ACL (filters based on source IP), Advanced ACL (filters based on multiple parameters like source and destination IP, protocol, and ports), and Layer 2 ACL (filters based on MAC addresses). User-defined ACLs are not a standard classification ​.

In Layer 3 roaming scenarios, STAs (stations) remain on different subnets before and after roaming. To ensure that user traffic reaches the original subnet, it must be tunneled back over a CAPWAP tunnel. This technique prevents disruptions in communication and enables seamless roaming. Huawei’s Layer 3 roaming design guidelines emphasize the use of CAPWAP tunnels for user traffic forwarding ​.

Explanation of IS-IS Packet Types and Synchronization Process:

In the given scenario, R2 requests LSPs from R1 to synchronize its Link State Database (LSDB). The following IS-IS packet types are involved in this synchronization process:

1. P2P IIH (Point-to-Point IS-IS Hello):

Purpose: Establishes and maintains IS-IS neighbor relationships.

Step: This packet is exchanged initially to detect and maintain the adjacency between R1 and R2.

2. PSNP (Partial Sequence Number PDU):

Purpose: Requests missing or outdated LSPs (Link State PDUs) from a neighbor to synchronize the LSDB.

Step: In this case, R2 sends a PSNP to R1 to request the missing or outdated LSP.

3. LSP (Link State PDU):

Purpose: Contains routing information and is used to update the LSDB.

Step: R1 sends the requested LSPs to R2 for synchronization.

4. CSNP (Complete Sequence Number PDU):

Purpose: Lists all LSPs in the sender ' s LSDB to help neighbors verify and request missing LSPs.

Step: R1 sends a CSNP during retransmission timeout to notify R2 of its LSPs.

The output shows that the router with the IP 10.0.12.2 is the Backup Designated Router (BDR), as indicated in the State: BDR field. The router ID is 10.0.2.2 , the interface cost is 1, and the IP address of the interface is 10.0.12.2 . Hence, C is the correct answer ​.
