STP loop guard is the correct protection feature. Cisco defines loop guard as a spanning-tree enhancement that prevents alternate or root ports from incorrectly becoming designated forwarding ports when expected BPDUs are no longer received. That failure mode is exactly what the question describes: an alternate or root port intermittently transitions to a designated role and creates a Layer 2 loop. With loop guard enabled, the port is placed into a loop-inconsistent blocking state until BPDUs are received again, so the topology remains protected. PortFast BPDU guard is intended for edge ports connected to end hosts and shuts a PortFast port when BPDUs appear; it is not the correct uplink/root-port protection. UDLD can detect unidirectional links, but it does not specifically enforce STP role consistency. Root guard prevents superior BPDUs from changing root placement, which is a different problem. Reference topics: STP loop guard, alternate and root ports, BPDU loss, loop-inconsistent state, Layer 2 loop prevention.

The design should use a scavenger queue for excessive or suspicious traffic and apply queuing on the access-to-distribution uplinks where congestion can occur. Cisco QoS campus design commonly uses a less-than-best-effort scavenger class to constrain traffic associated with worms, peer-to-peer applications, bulk background flows, or other nonbusiness traffic. Placing this traffic in a scavenger queue minimizes the bandwidth it can consume during congestion without harming real-time applications. Real-time voice or video traffic should be placed in a strict-priority queue so it receives low delay and low jitter treatment when links are congested. Applying queuing on access-to-distribution links is important because those uplinks are common campus congestion points, especially during bursts or abnormal traffic events. A shaping policy is not the right tool for campus LAN uplinks, and indiscriminate policing of real-time traffic can cause drops that damage voice and video quality. Reference topics: campus QoS, scavenger class, strict-priority queue, access uplink queuing, congestion management, worm mitigation.

Manual underlay is the correct deployment approach for a brownfield SD-Access scenario. In a greenfield fabric, Cisco DNA Center LAN Automation can build the routed underlay by discovering devices, assigning addresses, and creating the required underlay adjacencies. Brownfield environments already have an installed campus network, addressing plan, routing policy, operational constraints, and production dependencies. Rebuilding that underlay automatically can introduce unnecessary disruption. Cisco SD-Access brownfield designs normally preserve and validate the existing routed underlay, then use Cisco DNA Center to discover devices and automate the fabric overlay, policy, and endpoint segmentation functions. Subnet stretching is not the required deployment model and can create operational complexity. Automated underlay and LAN automation are powerful when the physical network is being newly built, but they are not the safest default for an established production environment. A professional brownfield design should first confirm MTU, routing reachability, loopback advertisements, device support, and fabric readiness before onboarding nodes. Reference topics: SD-Access brownfield migration, manual underlay, Cisco DNA Center, LAN Automation, fabric readiness.

Option A is the best addressing design because it gives each site enough capacity while avoiding excessive address waste and supporting summarization. A campus requiring 12,000 devices needs at least 14 host bits because 2^13 minus two is only 8190 usable addresses, while a /18 provides 16,382 usable addresses. That leaves room for growth without assigning an unnecessarily huge block. Each branch requiring 1,000 devices needs at least 10 host bits; a /22 provides 1,022 usable addresses, but /21 provides 2,046 usable addresses and additional growth capacity. The selected branch blocks, 10.0.192.0/21 and 10.0.200.0/21, are contiguous on valid /21 boundaries and can be summarized cleanly where appropriate. Option D fails because a /20 supports only 4094 usable addresses and cannot accommodate the 12,000-device campus. Option B overallocates a /16 to the campus and /20s to branches, wasting resources. Option C is grossly oversized and operationally poor. Reference topics: hierarchical IPv4 addressing, route summarization, VLSM, host-capacity planning, convergence containment.

EIGRP with branch routers configured as stubs and equal-cost multipath is the best fit for this hub-and-spoke DMVPN design. The branch routers have limited memory and CPU resources, so they should not be forced to maintain unnecessary topology information or answer broad queries from the rest of the network. EIGRP stub routing limits the routes a branch advertises and prevents it from being used as a transit path, which reduces query scope and improves stability. Because the two internet links are both 100 Mbps, equal-cost multipath can use both links for active forwarding during traffic spikes. OSPF can operate over DMVPN, but a single area or hub-and-spoke design may create more overhead and less efficient query containment for small branch routers. IS-IS is less common for this WAN overlay use case, and iBGP with route reflectors can scale but does not natively consider link utilization or provide the same simple branch stub behavior. Reference topics: EIGRP stub, DMVPN, ECMP, branch routing, query containment, WAN convergence.

The correct code snippet must use a secure HTTPS-based RESTCONF transaction with the YANG JSON media type. The requirement explicitly states that the content type is application/yang-data+json and that the connection to the network device must be secured. In Cisco IOS XE programmability, RESTCONF uses HTTP methods against YANG-modeled resources, and secure deployments use HTTPS rather than clear-text HTTP. A loopback interface with address 172.16.15.12/32 would be configured by sending a JSON payload that follows the selected YANG model structure, commonly an IETF or Cisco native interface model, with the correct content-type and authentication headers. The key security indicator in the option must therefore be HTTPS/TLS, not an insecure HTTP URL or a non-YANG content type. NETCONF over SSH would also be secure, but the stated content-type points to RESTCONF with JSON encoding. Option A is the valid snippet because it aligns the payload format with a secure transport. Reference topics: RESTCONF, YANG JSON encoding, application/yang-data+json, HTTPS, IOS XE programmability.

The required resource is the organization name. During manual WAN Edge onboarding, the device needs local system identity information and transport reachability so it can authenticate into the Cisco Catalyst SD-WAN overlay. Cisco onboarding workflows identify system parameters such as system IP, site ID, organization name, and vBond information as required configuration elements. The organization name must match the value configured across the SD-WAN controllers; otherwise, certificate validation and control connection establishment fail. After the WAN Edge authenticates with vBond, vBond helps it discover the vSmart controllers and vManage. That is why the vSmart hostname is not the first required onboarding resource in this question. NAT may exist in the path and vBond can assist traversal, but NAT itself is not the configuration identity item. A generic domain name is not the same as the SD-WAN organization name. Reference topics: Cisco SD-WAN onboarding, vBond orchestrator, organization-name, control connections, WAN Edge manual configuration.

The requirements point to a Layer 2 multipoint WAN service. VPLS provides an emulated Ethernet LAN across a provider network, allowing multiple sites to appear as if they are connected to the same Layer 2 domain. This supports full-mesh Layer 2 connectivity and preserves customer control over higher-layer services such as IPv6, multicast, routing protocols, and QoS markings. Because the provider delivers an Ethernet multipoint service, the enterprise can retain protocol independence rather than depending on the service provider to participate in IPv6 routing or multicast routing. CoS marking is also a Layer 2 QoS mechanism, so a Layer 2 VPN service is better aligned to the stated QoS requirement. VPWS is point-to-point rather than full-mesh multipoint, so it does not meet the topology requirement by itself. MPLS Layer 3 VPN is a provider-routed service and does not give the customer full Layer 2 mesh behavior. DMVPN is an overlay routed VPN and does not provide a native Layer 2 full-mesh service. Therefore, VPLS is the correct WAN connectivity option.
