Themidplane lid removal processis designed to betool-freeand follows aspecific sequence to avoid damage.

Thecorrect methodis:

Push in on the two handleslocated near thePCIe tray.

Slowly lift the midplane lid up, ensuring it does not catch on other components.

Remove the lid at an angleto avoid damaging adjacent connectors.

Why this method is used?

Theangled removalhelpsavoid contact with fragile connectorson the midplane.

Forcing the lid straight upcould damage PCIe slots or motherboard connectors.

Official Documentation Reference:

Supermicro AS-8125GS-TNMR2 Disassembly Manualdetails thecorrect method for removing the midplane lid.

Theyellow warning labelis a critical indicator toprevent damagewhen servicing themidplane and ribbon cable connections.

Reason for Warning Label:

Theflat panel/ribbon cable is delicateand isconnected between multiple system components.

If themidplane is removed first, itstretches and applies force on the ribbon cable, leading to:

Broken cable connectors

Torn ribbon cable

System interface failure(front panel controls, LED indicators, or data communication)

Why other options are incorrect?

A (Cable is hot)→ Ribbon cablesdo not generate heatand thisis not the purpose of the warning label.

B (Remove after midplane)→ Thecable must be removed BEFORE the midplane, not after.

C (Optional removal)→It is mandatory, not optional, to prevent damage.

Official Documentation Reference:

Supermicro AS-8125GS-TNMR2 Maintenance Manualstates thatremoving the flat panel/ribbon cable firstisa required stepbefore handling the midplane.

Theflap door mechanismis a protective feature inSupermicro MI300X systemsdesigned tosecure ribbon cable connections.

How to open it correctly?

Press down on the top of the flap door→ This disengages the locking mechanism.

The flap door will "pop open" safelywithout damaging the ribbon cable.

Forcing the flap without pressing down properly may break the connector.

Official Documentation Reference:

Supermicro AS-8125GS-TNMR2 Maintenance Manualprovidesspecific instructionsonpressing down the flap door before opening it.

Why Secure One End of the PCIe Tray First?

TheSupermicro MI300X chassis is designed for modular tray installation, meaningsecuring one end firstensures:

Proper alignment of PCIe slots and connectors

Stable mountingto prevent unwanted movement

Prevention of unnecessary strain on installed expansion cards

What Happens If Both Ends Are Handled at the Same Time?

ThePCIe tray may shift out of alignment, making it difficult to properly install other components.

Misalignment can cause:

PCIe devices to not seat properly

Power or data cables to be obstructed

Increased risk of mechanical damage during reinstallation

Step-by-Step Correct Installation Process:

✅Step 1:Align the PCIe tray with its designated mounting slots.✅Step 2:Secure screws onone end firstto hold the tray in place.✅Step 3:Adjust the other end and ensureproper seatingbefore fully tightening all screws.✅Step 4:Reconnect all PCIe cables and verify system connectivity.

Why Other Options Are Incorrect?

B (Cables getting in the way)→ While cable management is important, the main issue istray movement, not cable obstruction.

C (Tray will not function)→ The tray will functiononce properly seated, butincorrect installation can lead to PCIe misalignment.

D (Tray will break)→ The tray is designed for durability; it will not break unlessexcessive force is applied.

Official Documentation Reference:

Supermicro AS-8125GS-TNMR2 Service Guideconfirms thattrays must be secured at one end first to ensure proper alignment.

InSupermicro MI300X GPU systems, theNVMe backplane is located behind the motherboard tray, meaning the tray must be removed first.

Why is this step necessary?

The NVMe backplane is physically secured behind the motherboard trayto support high-speed PCIe connectivity.

Removing the motherboard tray provides clear accessto NVMe connectors and MCIO cables.

Skipping this step may cause unnecessary strain on cables, leading to potential connector damage.

Official Documentation Reference:

Supermicro Service Guide for NVMe Systemsconfirms that themotherboard tray must be removed firstbefore working on the NVMe backplane.
