PEGACPRSA22V1 Exam Dumps - Certified Pega Robotics System Architect 22

(Correct Order):

Start the interrogation for the Windows application.

Interrogate the Windows form.

Navigate to the window that contains the menu.

Select the control in the control hierarchy list.

In the More menu, select Add menu items.

In the Add Menu Items dialog box, select the menu items.

Click OK to save the selection

Unlike web or text-based controls, Windows application menus (such as File, Edit, or Help) are often rendered as non-standard Windows controls that cannot be directly interrogated using the bullseye tool.

Instead, Pega Robot Studio provides a specific method to add menu items through the interrogation hierarchy.

According to the Pega Robotics System Design and Implementation Guide, section “Interrogating Menu Items in Windows Applications”:

“Menu items in Windows applications are not directly interrogated through visual selection.

Instead, the process involves interrogating the parent form, identifying the menu control in the hierarchy, and then using the ‘Add Menu Items’ option to expose individual menu commands as controls.

Steps:

Start interrogation for the Windows adapter.

Interrogate the main form that contains the menu bar.

Navigate to the window containing the menu to ensure visibility.

In the control hierarchy, select the menu bar control.

From the More menu, choose Add menu items.

In the Add Menu Items dialog box, select the menu items to expose as interrogated controls.

Click OK to confirm and save your selections.”

Detailed Step Reasoning:

Start the interrogation for the Windows application.

Launches the adapter and begins the interrogation session.

Interrogate the Windows form.

Interrogates the main form containing the menu bar control (the top-level parent for menus).

Navigate to the window that contains the menu.

Ensures the correct active window is in focus for interrogation.

Select the control in the control hierarchy list.

Identifies the menu bar or parent control within the form’s hierarchy.

In the More menu, select Add menu items.

Opens the configuration dialog for menu interrogation.

In the Add Menu Items dialog box, select the menu items.

Displays a list of all available menu items to expose as automatable elements.

Click OK to save the selection.

Finalizes interrogation and creates the selected menu items as controls in the project hierarchy.

Final Ordered Steps:

Order

Interrogation Step

1

Start the interrogation for the Windows application.

2

Interrogate the Windows form.

3

Navigate to the window that contains the menu.

4

Select the control in the control hierarchy list.

5

In the More menu, select Add menu items.

6

In the Add Menu Items dialog box, select the menu items.

7

Click OK to save the selection.

To diagnose a failure occurring on a link from a control’s Properties call to a String service’s Equals(), you must place breakpoints on the event links immediately before the failing link so you can inspect the values being passed (for example, the account number) and confirm whether a null is being propagated.

Pega Robot Studio debugging guidance:

“Breakpoints can be set on event links to pause execution at specific steps in an automation. During a paused state, developers can inspect the values on connected data ports to determine whether null or unexpected values are being passed to the next step.”

“Place breakpoints upstream of the failing event to verify the value retrieved from a control (for example, via a Properties call) before it is sent into a service method (such as Equals).”

Option A shows a breakpoint on the event path feeding the Properties block and another just before the segment that calls Equals(). This allows you to stop exactly where the input to Equals(string2) would be evaluated and verify whether it is null.

Option C also places a breakpoint directly on the event link leading into the Properties/Equals segment, which is the correct spot to pause and inspect the data value before the comparison occurs.

Options B, D, and E place breakpoints either too early (not reaching the Properties/Equals path yet) or on unrelated branches, which won’t reliably expose the null value being passed into IStringService.Equals().

Application discovery is an early technical validation step that involves collecting the information about applications in scope of a potential robotics use case. During discovery you need to find out application types (and if they are on applications support matrix for Pega Robotics), how they are launched, how they are used, and check accessibility and functionality of the controls through interrogation. Application discovery is necessary to ensure that robotics use case is viable and it doesn't have any technical constraints... or, if constraints exist, then what kind of workarounds will be necessary to ensure the use case is successful. The rationale for having application discovery as a best practice is that you don't want to find out half-way through coding an automation that a key control is not available or not performing the desired action.
