FCP_FAZ_AN-7.6 Exam Dumps - Fortinet NSE 5 - FortiAnalyzer 7.6 Analyst

FortiAnalyzer has two primary operating modes:Analyzer modeandCollector mode. Each mode serves specific purposes and has distinct capabilities.

Option A - Forwarding Logs to a Syslog Server in Collector Mode:

In Collector mode, FortiAnalyzer collects logs from Fortinet devices but does not process or analyze them. Instead, it forwards the logs to other FortiAnalyzer units in Analyzer mode or to specific storage locations. However, forwarding logs to a syslog server is not a function of Collector mode. Logs are generally stored or sent to other FortiAnalyzer devices.

Conclusion:Incorrect.

Option B - Default Mode is Collector Mode Unless Configured for HA:

When a FortiAnalyzer is initially set up, it runs in Collector mode by default unless it is configured as part of a High Availability (HA) setup, whichwould set it to Analyzer mode. Collector mode prioritizes log collection and storage rather than analysis, offloading analysis to other devices in the network.

Conclusion:Correct.

Option C - Report Creation and Editing in Collector Mode:

In Collector mode, FortiAnalyzer does not have the capability to create or edit reports. This mode is focused solely on log collection and forwarding, with analysis and report generation left to FortiAnalyzer units operating in Analyzer mode.

Conclusion:Incorrect.

Option D - Performance Improvement with Both Modes in Topology:

Deploying FortiAnalyzer devices in both Collector and Analyzer modes in a network topology can enhance performance. Collector mode devices handle log collection, reducing the workload on Analyzer mode devices, which focus on log processing, analysis, and reporting. This separation of tasks can optimize resource usage and improve the overall efficiency of log management.

Conclusion:Correct.

Conclusion:

Correct Answer:B. FortiAnalyzer runs in collector mode by default unless it is configured for HAandD. A topology with FortiAnalyzer devices running in both modes can improve their performance.

These answers correctly describe the functionality and default configuration of FortiAnalyzer operating modes, along with how a mixed-mode topology can enhance performance.

When you frequently use the same search parameters in FortiAnalyzer’s Log View, setting up a reusable filter or view can saveconsiderable time. Here’s an analysis of each option:

Option A - Configure a Custom Dashboard:

Custom dashboards are useful for displaying a variety of widgets and summaries on network activity, performance, and threat data, but they are not designed for storing specific search filters for log views.

Conclusion:Incorrect.

Option B - Configure a Custom View:

Custom views in FortiAnalyzer allow analysts to save specific search filters and configurations. By setting up a custom view, you can retain your frequently used search parameters and quickly access them without needing to reapply filters each time. This option is specifically designed to streamline the process of recurring log searches.

Conclusion:Correct.

Option C - Configure a Data Selector:

Data selectors are used to define specific types of data for FortiAnalyzer reports and widgets. They are useful in reports but are not meant for saving and reusing log search parameters in Log View.

Conclusion:Incorrect.

Option D - Configure a Macro and Apply It to Device Groups:

Macros in FortiAnalyzer are generally used for automation tasks, not for saving log search filters. Applying macros to device groups does not fulfill the requirement of saving specific log view search parameters.

Conclusion:Incorrect.

Conclusion:

Correct Answer:B. Configure a custom view.

Custom views allow you to save specific search filters, enabling quick access to frequently used parameters in Log View.

Comprehensive and Detailed Explanation From Exact Extract of knowledge of FortiAnalyzer 7.6 Study guide documents:

B is true (members operate in analyzer mode, not collector mode):The study guide defines Fabric members as FortiAnalyzer devices that “retain access to the features described in the FortiAnalyzer Administration Guide” and that “each member can create or raise incidents and events.” In contrast, it states that a FortiAnalyzer operating incollector mode“does not provide capabilities for event management or reporting,” and also notes that “in collector mode, the GUI doesn’t include FortiView, Reports, or Incidents & Events.” Since Fabric members must be able to generate/manage incidents and events, they must be operating with analyzer capabilities rather than collector-only functionality.

C is true (members do not forward their logs to the supervisor):The supervisor provides centralized visibility, but the study guide describes the supervisor’s log access asviewing logs collected on members, not receiving/storing forwarded log files. It states: “In the FortiAnalyzer Fabric supervisor, Log View displays logs collected on all FortiAnalyzer Fabric members,” and clarifies “the logs contain the same information as displayed in the host FortiAnalyzer device they were collected on.” This indicates the logs remain on the member (host) and are made visible to the supervisor for centralized monitoring rather than being forwarded and stored on the supervisor.

For completeness, the study guide also explicitly states“HA is not available on the supervisor”(so A is false) andmembers do not need the same time zone as the supervisor(so D is false).
