500-220 Exam Dumps - Engineering Cisco Meraki Solutions (ECMS) v2.2

SM Sentry enrollment can be enabled on any MR network via the Splash page section of the Wireless > Configure > Access control page. https://documentation.meraki.com/MR/MR_Splash_Page/Systems_Manager_Sentry_Enrollment

This is because the SD-WAN policy for “All Databases & cloud services” has the following settings:

Uplink selection policy: Prefer WAN1, Fail over if down

Traffic filters: Custom performance classes

Custom performance classes: Database

Database performance criteria: Maximum latency 200 ms, Maximum jitter 20 ms, Maximum loss 1%

This means that the SD-WAN traffic will be routed via WAN1 by default, unless WAN1 is down or fails to meet the database performance criteria. In that case, the traffic will be routed via WAN2, if WAN2 meets the database performance criteria. Therefore, the condition that will cause the traffic to be routed via WAN2 is when WAN1 tunnel latency is 20 ms or more (which exceeds the maximum jitter of 20 ms), and WAN2 tunnel meets the configured performance criteria (maximum latency 200 ms, maximum jitter 20 ms, maximum loss 1%).

Which information is used to calculate whether a WAN link has high usage not how to view (To accurately identify high utilization, users must set the ISP-provided bandwidth limits under Security and SD-WAN > SD-WAN and Traffic Shaping > Uplink Configuration for each uplink. If the bandwidth usage is higher than 80% of the defined limit, it will mark that uplink as High Usage.) https://documentation.meraki.com/MI/MI_WAN_Health#:~:text=To%20accurately%20identify%20high%20utilization,that%20uplink%20as%20High%20Usage .

Route Priority

Each type of route configured on the MX has a specific priority in comparison with other types of routes. The priority is as follows:

Directly Connected

Client VPN

Static Routes

AutoVPN Routes

Non-Meraki VPN Peers

BGP learned Routes

NAT*

https://documentation.meraki.com/MX/Networks_and_Routing/MX_Routing_Behavior

https://www.ciscolive.com/c/dam/r/ciscolive/latam/docs/2019/pdf/BRKCRS-1579.pdf

This is because the alert mentions 802.1X failure, which is a network access control method that is used with WPA2-enterprise and RADIUS servers1.

This question is related to the topic of Wireless Access Points Quick Start in the Cisco Meraki documentation. You can find more information about this topic in the Wireless Access Points Quick Start article or the Using the Cisco Meraki Device Local Status Page page.

https://developer.cisco.com/meraki/api-v1/#!clone-organization
