H12-841_V1.5 Exam Dumps - HCIP-Datacom-Campus Network Planning and Deployment V1.5

Comprehensive and Detailed 200 to 250 words of Explanation From HCIP Datacom Campus Network documents knowledge without any URL or Links:

To deploy802.1X authenticationon Huawei campus switches and use aRADIUS serverfor user authentication and authorization, several core configuration components are mandatory. All four options listed are required for a complete and functional deployment.

Anauthentication domainis mandatory because it defines where user authentication requests are processed and which AAA schemes are used. Without a domain, the switch cannot determine how to handle authentication requests, makingoption A mandatory.

Anauthentication profileis also required. This profile binds authentication methods (such as 802.1X), authentication domains, and access policies together. Interfaces reference the authentication profile to determine how users are authenticated, sooption B is mandatory.

An802.1X access profiledefines detailed 802.1X parameters, such as authentication mode, reauthentication behavior, and client handling. This profile is bound to interfaces to enable 802.1X authentication on specific ports, makingoption C mandatory.

Finally, anAAA schemeis essential because it defines the authentication, authorization, and accounting methods used by the device, including RADIUS server configuration. Without an AAA scheme, the device cannot communicate with the RADIUS server or obtain user authorization information. Therefore,option D is mandatory.

According to HCIP Datacom Campus Network documentation, all four configuration steps are required to successfully enable 802.1X authentication with RADIUS-based access control.

Comprehensive and Detailed 200 to 250 words of Explanation From HCIP Datacom Campus Network documents knowledge without any URL or Links:

In VXLAN-based networks, inter-subnet communication and external network access requireLayer 3 forwarding capabilities. ALayer 3 VXLAN gatewayperforms routing between different VXLAN segments (VNIs) and enables traffic to exit the VXLAN overlay toward traditional non-VXLAN networks.

The NVE interface is responsible only for VXLAN encapsulation and decapsulation and does not perform routing. VLANIF interfaces are used in traditional VLAN environments and do not provide VXLAN interworking. A Layer 2 VXLAN gateway supports bridging only and cannot route between subnets.

Therefore, the Layer 3 VXLAN gateway is the correct solution for inter-subnet communication and external access.

Explanation (Based on HCIP Datacom Campus Network Design)

Position 1 → 802.1X AuthenticationThis authentication point corresponds to aPC connected to an access switch. PCs typically support 802.1X clients, making802.1X authenticationthe preferred and most secure method for wired user access. It provides strong identity-based access control using a RADIUS server.

Position 2 → Portal AuthenticationThis point representswireless user access. Portal authentication is commonly used for wireless terminals, especially guest or mobile users, where browser-based authentication is required. Users authenticate through a web page redirected by the access device.

Position 3 → MAC Address AuthenticationThis point corresponds tonon-802.1X-capable terminals, such as IP phones or printers. These devices cannot initiate 802.1X or Portal authentication, soMAC address authenticationis used to identify and authenticate them based on their MAC addresses.

This authentication deployment aligns with Huawei NAC best practices:

802.1X for capable wired terminals

Portal for wireless or guest access

MAC authentication for dumb or IoT devices

The displayed routes are EVPN routes shown in the formatNetwork(EthTagId/IpAddrLen/OriginalIp)with a /32 “OriginalIp” value (for example,0:32:1.1.1.0). In Huawei VXLAN BGP EVPN as described in HCIP Datacom Campus Network materials, this format corresponds toEVPN Route Type 3 (Inclusive Multicast Ethernet Tag Route). Type 3 routes are used by VTEPs to advertise participation information for a VXLAN broadcast domain (BD) and to provide the remote endpoint information needed for BUM (broadcast, unknown unicast, multicast) traffic handling.

Type 3 routes effectively carry theremote VTEP address information(the VTEP IP that serves as the tunnel destination in the underlay). Once the underlay Layer 3 network can reach that VTEP IP (for example, via IGP/BGP underlay routes), the VXLAN overlay can build forwarding toward the peer VTEP, so statementAis true and statementDis also true.

When ingress replication is used for BUM forwarding, the local VTEP needs a replication list of remote VTEPs in the BD. Receiving Type 3 routes provides the membership information required to form this list, making statementBtrue.

StatementCis false becauseType 2routes are MAC/IP Advertisement routes that include MAC information (and optionally a host /32 IP). The shown output contains no MAC fields, so it is not Type 2.

The displayed entries match the format of EVPN routes that carryVTEP reachability informationrather than host MAC/IP bindings or IP prefixes. The key clue is the field naming style shown asNetwork(EthTagId/IpAddrLen/OriginalIp)along with values like0:32:1.1.1.0, which indicates an IP address with a /32 length carried as the “OriginalIp”. In Huawei VXLAN BGP EVPN implementations described in HCIP Datacom Campus Network materials, this type of information corresponds toEVPN Route Type 3 (Inclusive Multicast Ethernet Tag Route).

Type 3 routes are used by VTEPs to signal membership information for a broadcast domain and to supportBUM (Broadcast, Unknown unicast, Multicast)forwarding behavior in the VXLAN fabric. Practically, they also provide the remote VTEP IP information needed so that, once the underlay can reach that VTEP IP address at Layer 3 (for example via IGP/BGP underlay routes), the local device can establish VXLAN encapsulation forwarding to that peer.

By contrast,Type 2routes would display MAC address information (and possibly a host /32 IP together with the MAC), andType 5routes would show IP prefixes like /24 or /30 used for inter-subnet routing.Type 1routes are related to Ethernet segments for multihoming (ESI), which is not what this output shows. Therefore, only statement A is true.

In Huawei campus network solutions,free mobilityis a user-centric access control mechanism designed to decouple network policies from physical locations and traditional network identifiers. According to HCIP Datacom Campus Network documentation, free mobility doesnotrely on VLAN IDs or IP addresses as the basis for policy management and permission control. Instead, it is implemented based onuser identity, such as user accounts, roles, user groups, or device identities.

Traditional networks often bind security policies to VLANs or IP subnets, which means users receive different permissions when they move to different access points or switch ports. This approach lacks flexibility and increases configuration complexity. Free mobility solves this problem by using centralized authentication and authorization mechanisms, such as 802.1X or MAC authentication combined with AAA, to dynamically assign policies after user authentication.

Once a user is authenticated, the network enforces access permissions based on predefined user roles or groups, regardless of where the user connects to the network. Even if the user’s IP address or VLAN changes due to roaming, the same security policy is consistently applied. This ensures seamless access experience, simplifies network management, and enhances security control.

Because free mobility isidentity-based rather than VLAN- or IP-based, the statement claiming that it implements policy management and permission control based on users' VLAN IDs and IP addresses is incorrect. Therefore, the correct answer isFALSE.

In Huawei campus networks, user access authentication is implemented through a standardized AAA framework that supports flexible authentication, authorization, and accounting methods. Statements A, B, and D correctly describe the authentication configuration process defined in HCIP Datacom Campus Network documentation. Administrators must first identify user domains and corresponding AAA schemes to ensure users are authenticated using appropriate methods. This is a foundational step for implementing network access control.

Access profiles and authentication profiles work together to define how users are authenticated. An authentication profile specifies the authentication mode, such as 802.1X or MAC authentication, while the access profile defines access control behavior. Binding these profiles and applying them to interfaces or VAP profiles enables consistent enforcement of access policies across wired and wireless networks.

When external authentication servers such as RADIUS or HWTACACS are used, interconnection parameters—including server IP addresses, shared keys, and ports—must be configured within the AAA scheme. This ensures reliable communication between network devices and authentication servers.

Statement C is false becauseiMaster NCE-Campus does support interconnection with third-party RADIUS servers. This capability allows enterprises to integrate existing authentication systems with Huawei campus solutions, improving compatibility and deployment flexibility. Therefore, the incorrect statement is option C.

In a VXLAN BGP EVPN architecture,EVPN Type 5 routes, also known asIP Prefix routes, are used to advertiseLayer 3 reachability informationbetween VXLAN segments. These routes are essential for implementing inter-VNI communication and external network connectivity through distributed or centralized gateways.

According to HCIP Datacom Campus Network documentation, a Type 5 route carriesIP prefix information, including theIP prefix and its prefix length, allowing VTEPs to learn network-level routing information rather than host-level details. TheRoute Distinguisher (RD)is also included to ensure uniqueness of routes across different VPN instances, which is critical in multi-tenant environments. Additionally, thegateway IP addressis carried to identify the next-hop gateway responsible for forwarding traffic toward the advertised prefix.

Unlike EVPN Type 2 routes, which advertiseMAC address and optional host IP address information, Type 5 routes donotcarry MAC addresses. Type 5 routes operate purely at the Layer 3 level and are independent of Layer 2 forwarding. Their purpose is to exchange subnet-level routing information rather than endpoint-level details.

MAC addresses are only relevant for Layer 2 forwarding and ARP/ND suppression, which are functions of EVPN Type 2 routes. Including MAC information in Type 5 routes would be unnecessary and inefficient for Layer 3 routing purposes.

Therefore, the field that isnot carriedin a BGP EVPN Type 5 route is theMAC Address, making optionCthe correct answer.
