AZ-700 Exam Dumps - Designing and Implementing Microsoft Azure Networking Solutions

You have an Azure subscription that contains the resources shown in the following table.

You need to ensure that network traffic is routed over the Azure backbone network for the following scenarios:

• Traffic from SQIMI1 to storage1

• Traffic from domain joined servers on VNet2 to storage1

The solution must minimize costs.

What should you configure for each scenario? To answer, select the appropriate options in the answer area.

NOTE: Each correct selection is worth one point.

Note: This question is part of a series of questions that present the same scenario. Each question in the series contains a unique solution that might meet the stated goals. Some question sets might have more than one correct solution, while others might not have a correct solution.

After you answer a question in this section, you will NOT be able to return to it. As a result, these questions will not appear in the review screen.

You have an Azure subscription that contains an Azure Virtual WAN named VWAN1. VWAN1 contains a hub named Hub1. Hub1 has a security status of Unsecured.

You need to ensure that the security status of Hub1 is marked as Secured.

Solution: You implement an Azure Front Door profile.

Does this meet the requirement?

You have an Azure subscription that contains the virtual machines shown in the following table.

Subnet1 and Subnet2 are associated to a network security group (NSG) named NSG1 that has the following outbound rule:

Priority: 100

Port: Any

Protocol: Any

Source: Any

Destination: Storage

Action: Deny

You create a private endpoint that has the following settings:

Name: Private1

Resource type: Microsoft.Storage/storageAccounts

Resource: storage1

Target sub-resource: blob

Virtual network: Vnet1

Subnet: Subnet1

For each of the following statements, select Yes of the statement is true. Otherwise, select No.

NOTE: Each correct selection is worth one point.

You have an on-premises network named Site1.

You have an Azure subscription that contains a virtual network named VNet1 and a storage account named storage1.

Site1 and VNet1 are connected by using a Site-to-Site (S2S) VPN.

You need to ensure that the servers in Site! can connect to storage! by using the S2S VPN The solution must minimize administrative effort.

What should you create on VNet1?

You have Azure App Service apps in the West US Azure region as shown in the following table.

You need to ensure that all the apps can access the resources in a virtual network named Vnet1 without forwarding traffic through the internet-How many integration subnets should you create?

You have an on premises web server that hosts a web app named App1 and has the following configurations:

• IP address 131.107.50.60

• FQDN server1.contoso.com

You have an Azure subscription.

You need to publish App1 by using Azure Front Door. The solution must meet the following requirements:

• Ensure that internet users can connect to App1 by using an FQDN of appl.contoso.com.

• Minimize the changes required to the configuration of Front Door if Server 1 is migrated to Azure.

What should you include in the solution? To answer, select the appropriate options in the answer area.

NOTE: Each correct selection is worth one point.

Your on-premises network contains an Active Directory Domain Services {AD DS) domain named contoso.com that has an internal certification authority (CA).

You have an Azure subscription.

You deploy an Azure application gateway named AppGwy1 and perform the following actions:

• Configure an HTTP listener.

• Associate a routing rule with the listener.

You need to configure AppGwy1 to perform mutual authentication for requests from domain-joined computers to contoso.com.

Which four actions should you perform in sequence? To answer, move the appropriate actions from the list of actions to the answer area and arrange them in the correct order.

You have an Azure subscription that contains a virtual machine named VM1, a virtual network interface card (NIC) named NIC1, and a Basic SKU public IP address named IP1. NIC1 is attached to VM1. IP1 is associated to NIC1.

You need to upgrade IP1 to the Standard SKU.

What should you do first?
